HINO 500 SERIES - FL8JW1A

FL8JW1A-XGM

Bringing HINO’s chassis versatility, HINO 500 Series is the ideal medium duty truck for operators.
Whatsapp

Email

Share Via
Download Brochure

Bringing HINO’s chassis versatility, HINO 500 Series is the ideal medium duty truck for operators. The outstanding range of trucks continues to offer medium duty trucks buyers total flexibility and satisfaction. The 500 series offers customers legendary fuel and operating efficiency. This is the right medium duty truck of your choice.

Interior

Airvents

Bed Space

Cooler

Ashtray

Center Clustor

Driver Seat

Exterior

Platform

Cab Step

Coupler

Bolt

Aerodynamic

Safety & Perfomance

Gear

Flame

Engine	Model			HINO J08E-WK (EURO 2)
	Type			Diesel, 4cy., 6-Cylinder Vertical in-line, Overhead Camshaft, Water Cooled
	Displacement (cc)			7,684
	Max Output (Jis Gross) (kW(PS)/rpm)			210 (285) / 2,500
	Max Torque (Jis Gross) (Nm(kgfm)/rpm)			892 (91) / 1,500
	Bore & Stroke (mm)			112 x 130
	Fuel Injection System			Electronic Control, Commonrail Type
	Air Intake System			Turbo Charged Intercooled
	Max Engine Speed (rpm)			2,750
Clutch	Type			Dry Single Plate With Damper Springs
	Diameter (mm)			380
Transmission	Model/No. Of Speed			M009/9-Speed/Manual
	Type			Nine(9) Forward and One (1) Reverse Speed, Direct Drive
	Ratio (1st - Top)			14.056/1.000
Axle	Front	Type		Reversed Elliot, "I" Section Beam
		Capacity (kg)		6,000
	Rear	Type		Full-Floating, Single Reduction, Single Speed by Hypoid Gearings
		Capacity (kg)		20,000
Brake	Service Brake Type			Drum Brake With Two Leading Shoes for Front and Rear Wheels with Auto Shoe Brake Adjuster
	Service Brake Control			Full Air, Dual Circuit, with Antilock Brake System (ABS)
	Parking Brake Type			Air Operated Spring Brake, Acting on Front and 1st Rear Axle
	Auxiliary Brake Type			Exhaust Brake
Suspension	Front		Type	Semi-Elliptic Leaf Springs (Reinforced Type) with Single Action Shock Absorber
	Rear		Type	Semi-Elliptic Leaf Springs
Frame	Frame Width (mm)			840
	Height x Width x Thickness (mm)			300 x 80 x 8.0
Cabin	Tilting			Mechanical Type
	Steering			Telescopic and Tilt Steering Column, Recirculating ball integral power steering
	Hino Connect			Equipped
	Power Window			Equipped
	Central Locking			Equipped
	Seat Belt			Equipped
Wheels & Tires	Wheel Type			Ten (10) - Stud Disc Wheel (ISO type)
	Wheel Size			22.5 x 8.25
	Tyre Type			Tubeless Type
	Tyre Size			295/80R22.5
Electrical	Type			12 V x 2, Series Connection
	Batteries			24V, 243kC (65Ah) at 20-hour rate
	Alternator Capacity			24V, 60 Amp
Fuel Tank Capacity	L			320

Performance

G.V.W Rating	kg	26,000
Performance	Max Speed (km/h)	90*(With Speed Limiter)
	Gradeability (tan0) %	43.8
Transmission Ratio	Model	M009
	1st	14.056
	2nd	9.647
	3rd	6.993
	4th	5.021
	5th	3.636
	6th	2.653
	7th	1.923
	8th	1.380
	9th	1.000
	Reverse	13.636
Rear Axle	Model	SH17
	Ratio	4.625

Dimension & Mass

Chassis Mass (Without standard tool set, with spare tyre)	Front Axle (kg)	3,435
	Rear Axle (kg)	3,815
	Total (kg)	7,250
Dimension	Wheelbase WB (mm)	6,430 + 1,350
	Overall Length OL (mm)	11,945
	Overall Width OW (mm)	2,490
	Overall Height OH (mm)	2,760
	Cab To Axle Center CA (mm)	6,275
	Rear Overhang ROH (mm)	2,875
	Front Tread FT (mm)	2,055
	Rear Tread RT (mm)	1,855
	Turning Radius (on tire) (mm)	11,900
	Seating Capacity	3
